Why Heavy Earthmoving Contractors Choose the WZ30-40 Backhoe Loader

• High-Torque 92kW 6-Cylinder Turbocharged Diesel: Powered by a heavy-duty 6-cylinder, 4-stroke liquid-cooled turbocharged diesel powerplant generating 92 kW, providing unmatched low-end torque reserves to drive a 22 MPa high-pressure hydraulic circuit and conquer 30° grade climbing under full load.
• Massive 3.5-Ton Loader Payload (1.75m³ Bucket / 48kN Breakout): Outfitted with an expansive 2,200 mm wide bucket, 48 kN breakout force, and an elevated 3,500 mm dump height (4,250 mm maximum lift height), easily clearing high-sided commercial tandem tippers and aggregate hoppers.
• Deep 3.5m Trenching Reach & 180° Backhoe Articulation: Independent rear backhoe digs down to 3,500 mm with 32 kN tearing force, a wide 4,600 mm reach, and 2,800 mm dump clearance across an expansive 180° swing arc for high-capacity spoil deposition without repositioning the undercarriage.
• Heavy-Duty Wheel Side Reduction Axles & 38 km/h Roading: Built on heavy-duty hub-reduction 4x4 drive axles with automatic hydraulic transmission (F2+R2), tall 16/70-24 traction tires, 280 mm ground clearance, and reliable air brakes, achieving swift highway and jobsite travel up to 38 km/h.

✔ Heavy 3.5-Ton Loader & 48kN Breakout Force: High-capacity 1.75 m³ front bucket with 4,250 mm maximum lifting height easily loads multi-axle tippers and batching hoppers in fewer passes.

✔ Deep 3.5m Foundation Digging & 32kN Dig Force: Large rear excavation envelope reaching 3.5m depth and 4.6m radius delivers robust trenching and spoil casting across full 180° articulation.

✔ 92kW 6-Cylinder Turbo Power & 38 km/h Roading: High-displacement 6-cylinder diesel paired with heavy hub-reduction axles and 16/70-24 tires guarantees immense pushing power and rapid highway mobilization.
