WZ30-25 Backhoe Loader
Operating Weight: 6 t
Dimensions: 7.6 × 2.1 × 3.1m
Power:76 kW
WZ30-25 Heavy-Duty Backhoe Loader | 6.0-Ton 4x4 Automatic 2.5-Ton Load & 4.1m Deep Dig
6,000kg Operating Mass | 2,500kg Front Loader (1.3m³) | 4,100mm Backhoe Dig Depth | 76kW Turbo Diesel | F4+R4 Automatic Powershift
Why Heavy Earthmoving Contractors Choose the WZ30-25 Backhoe Loader
- Deep 4.1m Excavation Envelope & 190° Boom Articulation: Features an impressive 4,100 mm vertical digging depth, 190° wide swing arc, and integrated cylinder buffering function with hydraulic leg locks, ensuring productive trenching and spoil casting across deep utility installations.
- 2.5-Ton Front Loader with 3,500mm Dump Clearance: Operates a heavy-duty 2,100 mm wide bucket (1.3 m³ capacity) with 38 kN breakout force and an elevated 3,500 mm dump height in rapid 9.5s cycles, easily clearing high-sided commercial tippers and aggregate bins.
- 76kW Turbo Diesel & F4+R4 Automatic Powershift: Driven by a 4-cylinder turbocharged liquid-cooled diesel engine paired with double pumps, a 280 dual high/low gearbox (F4+R4), high-frequency large hub reduction 4x4 axles, and air-over-oil caliper brakes for speeds up to 35 km/h.
- Forward-Tilting Deluxe Cab & Full Hydraulic Pilot Joysticks: Equipped with dual hydraulic pilot joysticks for loader and backhoe, large reversing camera, forward-tilting cab for rapid engine servicing, deluxe rotating suspension seat, LCD dashboard, and durable A-type or H-type stabilizing legs.
| Model | WZ30-25 |
| Operating Weight | 6000 kg (6.0 Ton) |
| Engine Power / Type | 76 kW Turbocharged / 4-Cylinder Water-Cooled Diesel |
| Front Loader (Rated Load / Capacity) | 2500 kg (2.5 Ton) / 1.3 m³ (Dump Height: 3500 mm) |
| Rear Backhoe (Dig Depth / Swing Angle) | 4100 mm (4.1 m) / 190° Full Swing |
| Transmission / Axles | F4+R4 Automatic Transmission | Large Hub-Reduction Axles (0–35 km/h) |
⬇️ View Full Technical Parameters & Dimensions ⬇️
| Machine Overall Specifications | |
| Operating Weight | 6000 kg |
| Overall Dimensions (L*W*H) | 7600 * 2100 * 3100 mm |
| Wheel Drive Type | 4x4 Full-Time Four-Wheel Drive |
| Drive Axle | High-frequency Heavy-duty Large Wheel Side Reduction Axle |
| Transmission Type | Hydraulic Automatic, 280 Dual High-Low Speed Gearbox (F4 + R4) |
| Steering System | Articulated Full-hydraulic Steering (Steering Angle: 36°) |
| Travel Speed | 0 – 35 km/h |
| Braking System | Air Over Oil Caliper Brake |
| Max. Gradeability | 30° |
| Min. Turning Radius | 5018 mm |
| Wheel Base / Wheel Tread | 2680 mm / 1600 mm |
| Min. Ground Clearance | 300 mm |
| Tire Size | 16/70-20 |
| Engine & Hydraulic System | |
| Engine Type | Diesel, 4-Cylinder, 4-Stroke, Water-Cooling, Turbocharger |
| Rated Power | 76 kW |
| Hydraulic System Architecture | Double Pump High-Pressure System |
| System Working Pressure | 22 MPa |
| Front Loader Technical Parameters | |
| Loader Rated Load / Capacity | 2500 kg / 1.3 m³ |
| Bucket Width | 2100 mm |
| Max. Dump Height / Distance | 3500 mm / 1022 mm |
| Max. Breakout Force | 38 kN |
| Total Actuation Time | 9.5 s |
| Rear Backhoe Technical Parameters | |
| Backhoe Bucket Capacity / Width | 0.3 m³ / 620 mm |
| Max. Digging Depth | 4100 mm (4.1 m) |
| Boom Swing Angle | 190° |
| Standard Cabin & Equipment Features | |
| Forward-Tilting Cab for Rapid Service, Hydraulic Joystick Pilot Operation for Loader & Backhoe, Large Reversing Camera, New Luxury Interior Cab, Deluxe Adjustable Rotating Suspension Seat, Adjustable Instrument Panel with LCD, Heater, Fan, Sash Windows, Skylight, LED Work Lights, Broken Window Hammer, Fire Extinguisher, Double Pump Hydraulic System, 280 Gearbox with Double High/Low Speed, A-Shaped or H-Shaped Hydraulic Outriggers with Locks, Backhoe Boom Buffering Function. | |
✔ Deep 4.1m Trenching Reach & 190° Swing: Massive excavation envelope reaching 4,100 mm depth with backhoe cylinder buffering and hydraulic leg locks delivers top-tier civil and municipal trenching productivity.
✔ 2.5-Ton Front Loader with 3.5m Dump Height: Moves 1.3 m³ batches with 38 kN breakout force and an extended 1,022 mm forward dumping reach for rapid truck and hopper loading.
✔ 76kW Turbo Power & Forward-Tilting Cab: Four-cylinder turbo diesel paired with F4+R4 automatic transmission, 300 mm ground clearance, and forward-tilting cabin structure ensures fast 35 km/h transit and zero-hassle routine maintenance.
